Full Intermeshing Bimetallic Screw And Barrel Hdpe Extruder Spare Parts

Full Intermeshing Bimetallic Screw And Barrel Hdpe Extruder Spare Parts

Full Intermeshing Bimetallic Screw And Barrel Hdpe Extruder Spare Parts
Full Intermeshing Bimetallic Screw And Barrel Hdpe Extruder Spare Parts
Full Intermeshing Bimetallic Screw And Barrel Hdpe Extruder Spare Parts
Product Details:
Place of Origin: Jiangsu, China (Mainland)
Brand Name: BLM-IV-1
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: packed and labeled according to the regulations and customer's requests.Great care is taken to avoid any damage which might otherwise be caused during storage or transportation.
Delivery Time: 25-30 days subject to the clients' requirement and quantity
Payment Terms: Western Union, L/C, T/T
Supply Ability: 1000 per Month
Contact Now
Detailed Product Description
Assembly Structure: Separate Type Extruder Engagement System: Full Intermeshing
Screw Channel Structure: Deep Screw Diameter: 12-350mm
Screw Design: Parallel Twin Screw Application: Materbatch,Plastic,Food,Chemical
Screw: Twin Screw Trademark: Wood Package
High Light:

Full Intermeshing Bimetallic Screw And Barrel

,

Full Intermeshing Bimetallic Screw Barrel

,

Hdpe Extruder Spare Parts Screw Barrel

High Quality bimetallic Screw And Barrel Hdpe Extruder Spare Parts



Descriptions

Material of Screw and Barrel:

Raw Material The Finished Product Processing Requirements
38CrMoAlA, SACM645, 42CrMo Nitriding Treatment
42CrMo, AISI 4140 Chrome Plating Hardness Layer
4Cr5MoSiV1, SKD-61, SKD-11 Spraying Bimetal Alloy Layer And Nitriding Treatment
HPM38, SI36, SUS440, 9Cr18MoV Stainless Steel(Iron), High Frequency Quenching
GHII3 Nature Harden After High Temperature
Full Intermeshing Bimetallic Screw And Barrel Hdpe Extruder Spare Parts 0
Full Intermeshing Bimetallic Screw And Barrel Hdpe Extruder Spare Parts 1



Standard screw elements and barrels

Full Intermeshing Bimetallic Screw And Barrel Hdpe Extruder Spare Parts 2





Twin screw barrel is gradually adopted by many manufacturers because of its high efficiency. Compared with single screw barrel, twin screw barrel has higher requirements for machining clearance. Our company has a professional team to help users solve design problems, and can also process according to the samples or drawings provided by customers.

injection screw barrel and bimetallic injection screw and barrel by materials 38CrMoAlA or 42CrMo and so on,for many type of injection mould machines,such as HAITIAN,CHEN HSONG,JSW,HAITAI,BRCHO,and so on.



Full Intermeshing Bimetallic Screw And Barrel Hdpe Extruder Spare Parts 3



1. Diameter of screw: D12-D300mm

2. L/D ratio of screw: 10 - 26



Grade available:

1. Standard grade: 38CrMoAlA + nitriding 96 hours

2. Bimetallic grade: 38CrMoAlA + bimetallic alloy

3. TC-A grade: Tungsten carbide 35%

4. TC-B grade: Tungsten carbide 25%

5. TC-C grade: Tungsten carbide 15%





Injection screw barrel and bimetallic injection screw and barrel

1)38CrMoALA(JIS SACM645)

2)42CrMo(JIS SCM440)

3)9Cr18MoV
4)CW6Mo5Cr4V2

5)Various high quality alloy steels,According to different usage, the choose for alloy is different, some require for abrasion-resistant while some require for corrsion-resistant. For standard, we have Fe-based, Ni-based,W2Calloy,Tunsten alloy etc for choice.



Application:

Rubber,various high glass fiber, mineral fiber and PPA,PPS, PA66, LCP,VO fire protection, ferrous power, magnetic powder and etc.


Treatment:
Heat-treatment
Nitriding treatment
Electroplate hard-chrome
High-frequency quenching
Spraying corrosion wear-resisting dual metal layers
Vacuum quenching





Bloom supplies cylinder barrel suitable for the following extruder products lines :
-APV -KOBE -OMC
-Buhler -KraussMaffei -Theysohn
-Buss -Berstorff- -Toshiba
-Clextral -Labtech -USEON
-Lantai - others
-JSW -Leistritz
-Keya -Maris




Size and capacity



Here is list of our general design data, which may be updated in some different circumstance.

Specification (d / D)

Working Length (mm)

Rotate Speed (rpm)

Capacity (kg/h)

Φ35/75

810

5-50

40-70

Φ45/90

990

5-45

50-80

Φ45/100

990

5-45

60-90

Φ48/112

1104

4-45

70-100

Φ50/105

1045

4-45

100-150

Φ51/105

1220

4-45

100-150

Φ55/110

1220

4-40

120-180

Φ55/120

1230

4-40

130-180

Φ58/126

1320

4-40

140-200

Φ60/125

1320

4-40

150-200

Φ65/120

1440

4-40

200-250

Φ65/132

1440

4-40

200-250

Φ68/146

1550

4-40

220-300

Φ80/143

1800

4-35

300-360

Φ80/156

1800

4-35

300-360

Φ92/188

2000

3-35

400-500





Types of Barrels
Standard for classification: Design geometry Standard for classification: With inner or not
* Feeding barrel * Solid barrel
* Closed barrel * Barrels with inners
* Vent barrel
* Combi barrel
* Extended degassing barrel
* Combi barrel with backward venting


We offer a broader choice of materials:
Solid barrels

*Nitrided steel barrels *Tooling steel barrels *Bimetallic


Barrel with installed inner
* made of PM-HIP solid *WR13
By working closely with customers in choosing optional materials,we can minimize wear and tear and associated costs.



Full Intermeshing Bimetallic Screw And Barrel Hdpe Extruder Spare Parts 4

Full Intermeshing Bimetallic Screw And Barrel Hdpe Extruder Spare Parts 5
