Extruder Single Feed Screw Barrel For Screw Extrusion Blow Molding Machine

Extruder Single Feed Screw Barrel For Screw Extrusion Blow Molding Machine

  • Extruder Single Feed Screw Barrel For Screw Extrusion Blow Molding Machine
  • Extruder Single Feed Screw Barrel For Screw Extrusion Blow Molding Machine
  • Extruder Single Feed Screw Barrel For Screw Extrusion Blow Molding Machine
  • Extruder Single Feed Screw Barrel For Screw Extrusion Blow Molding Machine
  • Extruder Single Feed Screw Barrel For Screw Extrusion Blow Molding Machine
  • Extruder Single Feed Screw Barrel For Screw Extrusion Blow Molding Machine
Extruder Single Feed Screw Barrel For Screw Extrusion Blow Molding Machine
Product Details:
Place of Origin: Jiangsu, China (Mainland)
Brand Name: BLM-IV-1
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: packed and labeled according to the regulations and customer's requests.Great care is taken to avoid any damage which might otherwise be caused during storage or transportation.
Delivery Time: 25-30 days subject to the clients' requirement and quantity
Payment Terms: Western Union, L/C, T/T
Supply Ability: 1000 per Month
Contact Now
Detailed Product Description
Assembly Structure: Separate Type Extruder Engagement System: Full Intermeshing
Screw Channel Structure: Deep Screw Diameter: 12-350mm
Screw Design: Parallel Twin Screw Application: Materbatch,Plastic,Food,Chemical
Screw: Twin Screw Trademark: Wood Package
High Light:

Full Intermeshing Screw Barrel

,

350mm Twin Screw Barrel

,

Single Feed Screw Barrel

Extruder Single Feed Screw Barrel for Screw Extrusion Blow Molding Machine And Injection Molding Machine





Descriptions

Twin screw barrel is gradually adopted by many manufacturers because of its high efficiency. Compared with single screw barrel, twin screw barrel has higher requirements for machining clearance. Our company has a professional team to help users solve design problems, and can also process according to the samples or drawings provided by customers.



Main Charactors:

Using machining center finishing, reasonable processing technology, advanced testing equipment, to ensure that the processing accuracy of each product.
Twin-screw extruder screw element:
- convenient interchangeability by agile combination.
- fulfill efficient self-cleaning, transmission, compounding, pressure-forming and etc.
- made of high speed tool steel W6Mo5Cr4V2, or anti-corrosion steel 38CrMoAlA by speed treatment.
The flexible modular principle is realized with screw barrel sections from the wide range of different designs possible. Fast, intensive and uniform heating of the screw barrel section is ensured by electrical heaters. The barrel sections are cooled with water by means of an internal bore system with bores arranged close to the inside barrel wall.





Bloom supplies cylinder barrel suitable for the following extruder products lines :
-APV -KOBE -OMC
-Buhler -KraussMaffei -Theysohn
-Buss -Berstorff- -Toshiba
-Clextral -Labtech -USEON
-Lantai - others
-JSW -Leistritz
-Keya -Maris




Size and capacity



Here is list of our general design data, which may be updated in some different circumstance.





Conical Screw Barrel Nominal Size Selection (Ref.)

Model

Power (KW)

Speed (RPM)

Output (KG/H)

Appliance

35/75

12

5-50

40-70

PVC Pipe
PVC Profle
PVC Sheet
PVC Board
PVC Recycling
PE Pipe

45/90

15

5-45

50-80

45/100

15

5-45

60-90

48/112

18.5

5-45

70-100

51/105

18.5

4-40

100-150

55/110

22

4-40

120-180

55/120

22

4-40

130-180

60/125

25

4-40

150-200

65/132

30

4-40

200-300

68/146

35

4-40

220-300

80/143

55

4-35

350-450

80/156

55

4-35

350-450

92/188

110

4-35

650-900

110/220

160

43951

950-1400




Types of Barrels
Standard for classification: Design geometry Standard for classification: With inner or not
* Feeding barrel * Solid barrel
* Closed barrel * Barrels with inners
* Vent barrel
* Combi barrel
* Extended degassing barrel
* Combi barrel with backward venting


We offer a broader choice of materials:
Solid barrels

*Nitrided steel barrels *Tooling steel barrels *Bimetallic


Barrel with installed inner
* made of PM-HIP solid *WR13
By working closely with customers in choosing optional materials,we can minimize wear and tear and associated costs.







Extruder Single Feed Screw Barrel For Screw Extrusion Blow Molding Machine 0

Extruder Single Feed Screw Barrel For Screw Extrusion Blow Molding Machine 1



All kinds of SJZ and SJP extruders that our company designs especially for producing the PVC pipe and profile, our extruders can promise a good plasticization, high capacity and advanced electric control, and the electrical cabinet can be chosen by customer according to their own demands.



Extruder Single Feed Screw Barrel For Screw Extrusion Blow Molding Machine 2
