4J36 Invar 36 Controlled Expansion Alloy Foil

4J36 Invar 36 Controlled Expansion Alloy Foil

4J36 Invar 36 Controlled Expansion Alloy Foil
4J36 Invar 36 Controlled Expansion Alloy Foil
4J36 Invar 36 Controlled Expansion Alloy Foil
Product Details:
Place of Origin: Jiangsu, China (Mainland)
Brand Name: BLM-IV-1
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: packed and labeled according to the regulations and customer's requests.Great care is taken to avoid any damage which might otherwise be caused during storage or transportation.
Delivery Time: 25-30 days subject to the clients' requirement and quantity
Payment Terms: Western Union, L/C, T/T
Supply Ability: 300 Ton/Tons per Month
Contact Now
Detailed Product Description
Equal Grades: 4J36,Nilo36 Width: 5-1400mm
Thickness: 0.005-0.05mm Product Name: Invar 36 Alloy
Shape: Foil Package: Plywood Case
High Light:

4J36 alloy foil


Invar 36 alloy foil


0.05mm alloy foil

4J36 Invar 36 Controlled Expansion Alloy Foil Thickness 0.005-0.05mm

1 . Descriptions:

Invar Alloy Foil is available in numerous thicknesses and tempers for applications requiring high dimensional stability and low thermal expansion.

Generally immediately available in most volumes,available in machined shapes such as bar,ingot,ribbon,wire,shot ,sheet,and foil.

Typical and custom packaging is available,as is additional research,technical and safety data.

invar 36 is a Nickel-Iron ,low expansion alloy containing 36% Nickel.It maintains nearly constant dimensions over the range of normal atmospheric temperatures and has a low coefficient of expansion form cryogenic temperatures to about   +500℃.Invar 35 also retains good atrength and thoughness at cryogenic temperature.





2 . Chemical compostion

Element C P S Si Mn Ni Fe
Weight(%) ≤0.05 ≤0.020 ≤0.02 ≤0.30 0.2~0.6 35.0~37.0 Bal



3 . Invar Mechanical Properties


Tensile Strength  ksi 75
  Mpa 518
Yield Strength  ksi 40
  Mpa 276
Elongation % in 2 in  34
Typical Hardness Ann. Rockwell HRB 80
Modules of Elasticity  Mpsi 20.5
  kMPa 141



   Electrical circuit breakers

   Temperatuer regulators

   Clock balance wheels

   Pendulum clocks

   Precision condenser blades

   Radar and microwave cavity resonators
