SKD Bimetallic Conical Twin Screw For UPVC Water Supply Drainage Pipe

SKD Bimetallic Conical Twin Screw For UPVC Water Supply Drainage Pipe

  • SKD Bimetallic Conical Twin Screw For UPVC Water Supply Drainage Pipe
  • SKD Bimetallic Conical Twin Screw For UPVC Water Supply Drainage Pipe
  • SKD Bimetallic Conical Twin Screw For UPVC Water Supply Drainage Pipe
SKD Bimetallic Conical Twin Screw For UPVC Water Supply Drainage Pipe
Product Details:
Place of Origin: Jiangsu,China
Brand Name: BLM
Certification: ISO
Model Number: BLM-S
Payment & Shipping Terms:
Minimum Order Quantity: 10PCS
Price: Negtation
Packaging Details: Packing with wooden box
Delivery Time: 25days
Payment Terms: T/T
Supply Ability: 500pcs per month
Contact Now
Detailed Product Description
Type: KMD60 KMD75 KMD90 KMD110 KMD114 KMD130 Base Material: 38CrMoAlA,SACM645,42CrMo,SKD61,GH113,etc
Bimetallic Screw Process: Spray Welding Bimetallic: Fe-based,Ni-based,Tungsten Carbide
End Products: Recycled PE,PP,ABS,EPS,XPS,PC Pelletizing Extruder Diameter For Single Screw: 45/90,51/105,55/110,65/132,80/156,80/172,92/188
High Light:

Bimetallic Conical Twin Screw

,

Spray Welding Conical Twin Screw

Factory Direct Sale SKD And Bimetallic Conical Twin Screw SZ55/110 For UPVC Water Supply-Drainage Pipe



1 .  Material: 38CrMoAIA

Nitriding treatment, Surface hardness: HV≥900

Nitriding depth: 0.5-0.8mm





2 . Base material: 38CrMoAIA

Special alloy is welded on the flight of screw, prolong life of screw.





3 . Easy wearing parts of barrel made from anti-wear alloy can be improved abrasion performance.

For good plasticizing effect, we have different design of screw barrel to meet

customer's demand.

Gradual type, mutant type, wave type, barrier type, double screen type, shunt

type, separation type, exhaust type, pin type, mixed type, double-head type,

three-head type, multi head type etc.





4 . Refer to the following specification and small part be designed according to the compression ratio:

Φ15/Φ30 Φ25/Φ55 Φ35/Φ75 Φ40/Φ83

Φ45/Φ90-99 Φ48/Φ112-117 Φ50/Φ105-110 Φ51/Φ105-120

Φ55/Φ110-125 Φ58/Φ125 Φ60/Φ125-129 Φ65/Φ120-132

Φ68/Φ147 Φ70/Φ150 Φ74/Φ156-162 Φ80/Φ143-156-162

Φ86/Φ177 Φ92/Φ184-188 Φ95/Φ193 Φ105/Φ203





5. Scope of application:

WPC PVC. WPC PE, Super high molecular sheet, 1/2 high

Calcium buckle, 50-400 high Calcium pipe, 50-300 high Calcium Profile, soft

PVC sheet, XPS-PVC etc.

PP,PE,ABS,PVC, raw material, pelletzing, pipe, profile, sheet etc.



SKD Bimetallic Conical Twin Screw For UPVC Water Supply Drainage Pipe 0
